XR-Aluma-Pro family breakdown
Return to the full air/water family lookup.
Open support page
MIG spool gun support
XR-Aluma-Pro water-cooled parts lookup for the XR-Aluma-Pro push-pull gun family. Stock numbers: 301571 / 301572 / 301573. Rated output: 400 A at 100% duty cycle. Wire range:.030 - 1/16 in. aluminum wire. Use the diagram and parts table to identify XR consumables before ordering.
As an Amazon Associate, I earn from qualifying purchases.
| Item # | Part # | Description | Qty | Buy |
|---|---|---|---|---|
| Gun | 301571 / 301572 / 301573 |
XR-Aluma-Pro water-cooled, 15, 25, or 35 ft., 400 A at 100% duty cycle
|
1 | N/A |
| 2 | 230969 |
Head tube O-rings
|
1 | Check Price on Amazon |
| 3 | 227168 |
Lock Nut
|
1 | Check Price on Amazon |
| 4 | 227416 |
Insulator Ring Rear
|
1 | Check Price on Amazon |
| 5 | 227158 |
Head Tube Short
|
1 | Buy link unavailable. |
| 5 | 229672 |
Head Tube Long
|
1 | Buy link unavailable. |
| 6 | 227159 |
Insulating Jacket, short
|
1 | Check Price on Amazon |
| 6 | 229673 |
Insulating Jacket, long
|
1 | Buy link unavailable. |
| 7 | 229670 |
Gas Diffuser
|
1 | Check Price on Amazon |
| 8 | 206186 |
FasTip contact tip .041 ID
|
1 | Check Price on Amazon |
| 8 | 206187 |
FasTip contact tip .047 ID
|
1 | Check Price on Amazon |
| 8 | 206188 |
FasTip contact tip .053 ID
|
1 | Check Price on Amazon |
| 8 | 206189 |
FasTip contact tip .061 ID
|
1 | Check Price on Amazon |
| 8 | 206190 |
FasTip contact tip .071 ID
|
1 | Check Price on Amazon |
| 9 | 198855 |
Nozzle, standard
|
1 | Check Price on Amazon |
| Flex | 267517 |
Flex Head
|
1 | Check Price on Amazon |
| Drive | 227434 |
Drive Rolls
|
1 | Check Price on Amazon |
| Drive | 227439 |
Idler Rolls
|
1 | Check Price on Amazon |
| Drive | 230710 |
Idler Rolls
|
1 | Check Price on Amazon |
| Guide | 227408 |
Inlet Guides
|
1 | Check Price on Amazon |
| Guide | 230711 |
Inlet Guides
|
1 | Buy link unavailable. |
| Liner | 229887 |
Cable liner, 15 ft.
|
1 | Check Price on Amazon |
| Liner | 229891 |
Cable liner, 25 ft.
|
1 | Check Price on Amazon |
| Liner | 232321 |
Cable liner, 35 ft.
|
1 | Check Price on Amazon |
| Liner | 233999 |
Cable liner, long
|
1 | Check Price on Amazon |
| Liner | 233998 |
Cable liner, short
|
1 | Buy link unavailable. |
Related consumables
Return to the full air/water family lookup.
Open support pageLighter industrial XR gun.
Open support pagePlus-generation XR gun family.
Open support pageMachine path connected to this spool gun family.
Open machine pageMachine path connected to this spool gun family.
Open machine pageMachine path connected to this spool gun family.
Open machine page
These accessories are placed here only when the Miller catalog names this machine, torch, feeder, or family path. Verify plug style, voltage, package, and serial-specific details before ordering.
| Part | Accessory | Catalog fitment | Source / path |
|---|---|---|---|
| 195461 | Coolant Flow Switch | Water-cooled guns; verifies coolant flow before welding. | Catalog p. 121 Open support path |
| 043810 | Low-Conductivity Coolant | For TIG and MIG water-cooled systems where aluminum is not in the coolant path/circuit. | Catalog p. 123 Open support path |
| 043809 | Aluminum-Protecting Coolant | Primarily for push-pull guns where aluminum is in the coolant path/circuit and high frequency is not used. | Catalog p. 123 Open support path |
