XR-Pistol-Pro
Non-Plus pistol-style push-pull path.
Open support page
MIG spool gun support
XR-Pistol Plus guns are Plus-generation pistol-style push-pull guns for heavy industrial aluminum work.
As an Amazon Associate, I earn from qualifying purchases.
| Item # | Part # | Description | Qty | Buy |
|---|---|---|---|---|
| Gun | 300753 / 300754 |
XR-Pistol Plus air-cooled, 15 or 25 ft., 200 A at 100% duty cycle
|
1 | N/A |
| Gun | 300757 |
XR-Pistol Plus water-cooled, 25 ft., 400 A at 100% duty cycle
|
1 | N/A |
| Tip | 206186 |
FasTip contact tip .041 ID
|
10 or 25 pack | Buy on Amazon |
| Tip | 206187 |
FasTip contact tip .047 ID
|
10 or 25 pack | Buy on Amazon |
| Tip | 206188 |
FasTip contact tip .053 ID
|
10 or 25 pack | Buy on Amazon |
| Tip | 206189 |
FasTip contact tip .061 ID
|
10 or 25 pack | Buy on Amazon |
| Tip | 206190 |
FasTip contact tip .071 ID
|
10 or 25 pack | Buy on Amazon |
| Drive | 194114 |
XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 194115 |
XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 196302 |
XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 194116 |
XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 194117 |
XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 198434 |
Optional isolated XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 198435 |
Optional isolated XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 198436 |
Optional isolated XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 198437 |
Optional isolated XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Drive | 198438 |
Optional isolated XR-Edge drive roll
|
1 | Amazon link: Needs verification. |
| Liner | 191065 |
Cable liner, 15 ft. or 30 ft.
|
1 | Amazon link: Needs verification. |
| Liner | 191066 |
Cable liner, 50 ft.
|
1 | Amazon link: Needs verification. |
| Liner | 197440 |
Cable liner, 500 ft.
|
1 | Amazon link: Needs verification. |
| Nozzle | 197728 |
Nozzle, 5/8 in. orifice
|
1 | Amazon link: Needs verification. |
| Nozzle | 050116 |
Nozzle, 13/16 in. orifice
|
1 | Amazon link: Needs verification. |
| Kit | 273232 |
Kit, Flex Head 10 in. for XR-A Pistol and Spoolmatic Gun
|
1 | Buy on Amazon |
| Kit | 267517 |
Kit, Flex Head, XR Aluma-Pro, Pistol-Pro, Pistol-Plus and Spoolmatic Pistol Pro
|
1 | Amazon link: Needs verification. |
| 1 | 198855 |
Nozzle, brass
|
1 | Buy on Amazon |
| 2 | 206187 |
Tip, FasTip .312 OD .040 and .035 aluminum wires
|
3 | Buy on Amazon |
| 2 | 206189 |
Tip, FasTip .312 OD .052 and 3/64 aluminum wires
|
3 | Buy on Amazon |
| 3 | 229670 |
Diffuser, .281/.312 OD collar FasTip
|
1 | Buy on Amazon |
| 4 | 229889 |
Nut, head tube rotation water
|
1 | Amazon link: Needs verification. |
| 5 | M1575 |
Tube, body, head flexible XR Pistol guns
|
1 | Amazon link: Needs verification. |
| 5 | M1516 |
Tube, body, head flexible AP/PP/SP guns
|
1 | Amazon link: Needs verification. |
| 6 | 134800 |
O-Ring, .614 ID x .070 CS 70 Duro Buna-N
|
2 | Amazon link: Needs verification. |
| 7 | M1507 |
Liner, Teflon .030-.035 wire AP
|
1 | Amazon link: Needs verification. |
| 7 | M1508 |
Liner, Teflon .047-.062 wire AP
|
1 | Amazon link: Needs verification. |
| 7 | M1509 |
Liner, Teflon .030-.035 wire PP/SP
|
1 | Amazon link: Needs verification. |
| 7 | M1514 |
Liner, Teflon .047-.062 wire PP/SP
|
1 | Amazon link: Needs verification. |
| Kit | M1502 |
Kit, Contact Tips, XR Pistol
|
1 | Amazon link: Needs verification. |
| 10 | 144862 |
Extension nozzle
|
1 | Amazon link: Needs verification. |
| 11 | 130632 |
Insulator ring
|
1 | Amazon link: Needs verification. |
| 15 | 153667 |
Clamp, stainless bundle
|
1 old style / 2 new style | Amazon link: Needs verification. |
| 16 | 212679 |
Tube, head flexible
|
1 | Amazon link: Needs verification. |
| 17 | 134800 |
O-Ring, .614 ID x .070CS
|
2 | Amazon link: Needs verification. |
| 18 | 131171 |
Tubing, convoluted
|
1 | Amazon link: Needs verification. |
| 19 | 222853 |
Liner, Teflon .030-.035 wire x 11.625 lg, black
|
1 | Amazon link: Needs verification. |
| 19 | 191003 |
Liner, Teflon .047-.062 wire x 11.625 lg, yellow
|
1 | Amazon link: Needs verification. |
| 19 | 212401 |
Liner, phos bronze .030-1/16 wire x 11.249
|
1 | Amazon link: Needs verification. |
| 20 | 134799 |
O-Ring, .176 ID x .070CS
|
1 | Amazon link: Needs verification. |
| 21 | 212680 |
Flex torch, inside tubing
|
1 | Amazon link: Needs verification. |
Related consumables
Non-Plus pistol-style push-pull path.
Open support page
Match the part number, machine model, gun or torch family, package quantity, and generation before buying. Amazon links are convenience links only, not compatibility proof.
