XR-Pistol air-cooled parts lookup for the XR-Pistol push-pull gun family. Stock numbers: 198127 / 198128. Rated output: 200 A at 100% duty cycle. Wire range:.030 - 1/16 in. aluminum wire. Use the diagram and parts table to identify XR consumables before ordering.
As an Amazon Associate, I earn from qualifying purchases.
| Item # | Part # | Description | Qty | Buy |
|---|---|---|---|---|
| Gun | 198127 / 198128 |
XR-Pistol air-cooled, 15 or 30 ft., 200 A at 100% duty cycle
|
1 | N/A |
| Tip | 206186 |
FasTip contact tip .041 ID
|
10 or 25 pack | View on Amazon |
| Tip | 206187 |
FasTip contact tip .047 ID
|
10 or 25 pack | View on Amazon |
| Tip | 206188 |
FasTip contact tip .053 ID
|
10 or 25 pack | View on Amazon |
| Tip | 206189 |
FasTip contact tip .061 ID
|
10 or 25 pack | View on Amazon |
| Tip | 206190 |
FasTip contact tip .071 ID
|
10 or 25 pack | View on Amazon |
| Drive | 194114 |
XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 194115 |
XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 196302 |
XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 194116 |
XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 194117 |
XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 198434 |
Optional isolated XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 198435 |
Optional isolated XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 198436 |
Optional isolated XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 198437 |
Optional isolated XR-Edge drive roll
|
1 | Buy link unavailable. |
| Drive | 198438 |
Optional isolated XR-Edge drive roll
|
1 | Buy link unavailable. |
| Liner | 191065 |
Cable liner, 15 ft. or 30 ft.
|
1 | View on Amazon |
| Liner | 191066 |
Cable liner, 50 ft.
|
1 | View on Amazon |
| Liner | 197440 |
Cable liner, 500 ft.
|
1 | Buy link unavailable. |
| Nozzle | 197728 |
Nozzle, 5/8 in. orifice
|
1 | View on Amazon |
| Nozzle | 050116 |
Nozzle, 13/16 in. orifice
|
1 | Buy link unavailable. |
| Extension | 132228 |
Hose and cable extension kit, 25 ft.; Spoolmatic only
|
1 | Buy link unavailable. |
| Extension | 132229 |
Hose and cable extension kit, 50 ft.; Spoolmatic only
|
1 | Buy link unavailable. |
| Cover | 241159 |
Leather cable cover, 15 ft.
|
1 | Buy link unavailable. |
| Cover | 241160 |
Leather cable cover, 30 ft.
|
1 | Buy link unavailable. |
| Canister | 132230 |
One-pound spool canister for small wire jobs
|
1 | Buy link unavailable. |
| Head Tube | 222462 |
50-degree curved head tube, air-cooled, for FasTip consumables
|
1 | Buy link unavailable. |
| Head Tube | 273232 |
10-inch flex head, air-cooled
|
1 | View on Amazon |
| Head Tube | 222461 |
10-inch straight head tube, air-cooled
|
1 | Buy link unavailable. |
| Nozzle Kit | 147174 |
50-degree curved nozzle kit for old-style multi-piece head tubes
|
1 | View on Amazon |
| Nozzle Kit | 300161 |
50-degree curved nozzle kit for newer Roughneck-style head tubes
|
1 | Buy link unavailable. |
| Tip | 148155 |
Replacement contact tips for 50-degree curved nozzle, .030 and .035 in. wire
|
1 | Buy link unavailable. |
| Tip | 148154 |
Replacement contact tips for 50-degree curved nozzle, .047 in. wire
|
1 | Buy link unavailable. |
| Tip | 148156 |
Replacement contact tips for 50-degree curved nozzle, 1/16 in. wire
|
1 | Buy link unavailable. |
| Liner | 212411 |
Replacement liner for 50-degree curved head tube
|
1 | View on Amazon |
| Liner | 222853 |
Replacement liner for 10-inch flex head
|
1 | Buy link unavailable. |
| Liner | 222854 |
Replacement liner for 10-inch flex head
|
1 | Buy link unavailable. |
| Liner | 212401 |
Replacement liner for 10-inch straight head tube
|
1 | Buy link unavailable. |
