Processes
Stick (SMAW), TIG (GTAW); Venture 150 T adds high-frequency TIG and pulsed TIG.
Miller Battery-Powered TIG / Stick Machine Support
Venture 150 Series
The Miller Venture 150 is a battery-powered stick/TIG welding power source with swappable 400 Wh battery packs. The Venture 150 S supports stick and lift-arc TIG; the Venture 150 T adds high-frequency TIG, pulsed TIG, a built-in gas solenoid, and the TIG contractor kit path. This page uses Miller BP/1.0, issued February 2026.
Stick (SMAW)TIG (GTAW)High-frequency TIG on 150 TPulsed TIG on 150 T
Battery-poweredBP/1.0
Output range
Stick: 20-150 A; TIG: 10-160 A
Battery system
52.8 V battery system; 400 Wh pack name and 396 Wh specification value
Charging
0-95% in less than 30 minutes fast charge; less than 60 minutes standard charge
Weight
27 lb. with battery pack
Open-circuit voltage
80 VDC maximum; low-OCV stick mode can reduce OCV to 12-16 V
Dimensions
13.2 H x 8.4 W x 19 D in.
Source
Miller BP/1.0, issued February 2026
Venture 150 S and T Differences
| Model | Processes and controls | Package path |
|---|---|---|
| Venture 150 S | Stick, Stick 6010 mode, and lift-arc TIG. Adaptive Hot Start, Stick-Stuck, low-OCV stick, and 100% duty cycle at maximum output. | Battery pack and charger packages; 301882 A-150 two-piece torch is the catalog-recommended TIG path. |
| Venture 150 T | Stick, Stick 6010 mode, high-frequency TIG, lift-arc TIG, and pulsed TIG / QuietPulse. Adds 6-pin remote connection, integrated gas valve, preflow/postflow, and pulse controls. | TIG contractor kit 301922 packages the 12.5 ft A-150 torch, RMS-6M hand control, regulator, gas hose, and AK2C accessory kit. |
Machine Packages
| Stock number | Catalog package |
|---|---|
| 951000202 | Venture 150 S with battery pack and charger |
| 951000221 | Venture 150 S with two battery packs and charger |
| 907888 | Venture 150 S power source only |
| 951000256 | Venture 150 T with battery pack, charger, and TIG contractor kit |
| 951000257 | Venture 150 T with two battery packs, charger, and TIG contractor kit |
| 951000258 | Venture 150 T with TIG contractor kit, no battery pack or charger |
| 907889 | Venture 150 T power source only |
Compatible Accessories
Venture 150 400 Wh Battery Pack
301756 Catalog-listed battery pack for Venture 150 packages.
Open accessory supportVenture 150 Battery Charger
301755 Catalog-listed charger for Venture 150 battery packs.
Open accessory supportTIG Contractor Kit
301922 Venture 150 T kit with A-150 torch, RMS-6M hand control, regulator, gas hose, and AK2C accessory kit.
Open accessory supportCompatible TIG Torch Paths
Weldcraft A-150 TIG Torch
301882 Two-piece A-150 torch path recommended for the Venture 150 S model.
Open A-150 / WP17 supportVenture 150 T TIG Contractor Kit
301922 includes the 12.5 ft. Weldcraft A-150 torch with flow-thru Dinse-style connector, 13.25 ft. RMS-6M hand control, flow-gauge regulator, 12 ft. gas hose, and AK2C accessory kit.
Find A-150 consumablesBP/1.0 Ordering and Accessory List
These part and stock numbers are transcribed from the supplied Venture 150 sheet. Use the model and connector notes before ordering. Items without an approved buy link route to Find My Part for identification and review.
| Part / stock | Item | Catalog relationship | Lookup |
|---|---|---|---|
| 301882 | Weldcraft A-150 two-piece TIG torch | Recommended for Venture 150 S; 150 A air-cooled torch with 25 ft cable. | Find My Part |
| WP1712MFDI50 | Weldcraft A-150 TIG torch | Recommended for Venture 150 T; 150 A air-cooled torch with 12.5 ft cable. | Find My Part |
| AK2C | TIG torch accessory kit | Venture 150 T path; short back cap, #4/#5/#6 nozzles, collets, collet bodies, and .040/1/16/3/32 in. 2% ceriated tungsten. | Find My Part |
| 401790 | RMS-6M remote | 13.25 ft. remote on/off control for Venture 150 T. | Find My Part |
| 195269 | RMS-6M remote | 26.5 ft. remote on/off control for Venture 150 T. | Find My Part |
| 195184 | RCCS-6M remote | 13.25 ft. remote fingertip control for Venture 150 T. | Find My Part |
| 195503 | RCCS-6M remote | 26.5 ft. remote fingertip control for Venture 150 T. | Find My Part |
| 301587 | RFCS-6M remote | 13.25 ft. remote foot control for Venture 150 T. | Find My Part |
| 301588 | RFCS-6M remote | 20 ft. remote foot control for Venture 150 T. | Find My Part |
| 301580 | Wireless remote foot control | 90 ft. operating range; requires 14-pin to 6-pin adapter cord 300507. | Find My Part |
| 301589 | RFCS-14 HD | Heavy-duty foot control for the Venture 150 T path; requires adapter cord 300507. | Find My Part |
| 300507 | 14-pin to 6-pin adapter cord | Required for the listed 14-pin remote paths. | Find My Part |
| 301756 | Venture 150 battery pack | 400 Wh swappable battery pack engineered for Venture 150. | Find My Part |
| 301755 | Venture 150 battery charger | Standard 120 V plug-in charger; fast charge 0-95% in less than 30 minutes and standard charge in less than 60 minutes. | Find My Part |
Stick Lead Path
Stick Leads, Electrode Holders & Work Clamps
Venture packages list 50 mm Dinse-style connectors for the electrode holder and work cable.
Open stick accessoriesChoose welding cable length
Included / Package Notes
Included With Venture Packages
- 400 Wh battery pack or battery packs, depending on package; the specification table lists 52.8 V and 396 Wh
- Battery charger on battery package stock numbers
- 10 ft. cable with electrode holder and 50 mm Dinse-style connector
- 10 ft. work cable with clamp and 50 mm Dinse-style connector
- Shoulder strap with pad and eight rubber bumpers/feet
Venture 150 T Adds
- High-frequency TIG arc initiation
- Pulsed TIG operation
- Built-in gas solenoid
- Available TIG contractor kit with Weldcraft A-150 torch path
Next Lookup Step
After you identify the Venture package, open the A-150 / WP17 torch page for cups, collets, gas lenses, back caps, and tungsten setup. Use the accessory support path for batteries, charger, and TIG kit checks.
Need More Help?
TIG Support
Use the A-150 / WP17 path when the question is torch front-end consumables, tungsten size, cup style, or gas lens fitment.
Accessory Support
Use Miller TIG accessories for the battery pack, charger, contractor kit, hand control, regulator, gas hose, AK2C kit, and adapter cord paths.
Search
Use Find My Part with Venture 150, 907888, 907889, 951000202, 951000256, 301922, 301756, 301755, or a remote part number.
Source: Miller Electric Venture 150 Series specification sheet BP/1.0, issued February 2026, pages 1-4. Machine specifications, model differences, package stock numbers, accessory relationships, and included cable/connector details are based on the supplied document. The existing approved Amazon battery and charger links were preserved; other items route to support lookup.
