T100M-2 Machine Torch torch assembly and replacement parts from the Hypertherm parts catalog. Match the item number on the breakdown to the parts list before ordering.
As an Amazon Associate, I earn from qualifying purchases. Buy buttons only appear where a WSP-approved Amazon registry match exists.
| Item # | Part # | Description | Qty | Buy |
|---|---|---|---|---|
| Torch | 059501 |
Hypertherm Torch Assembly 059501
|
Verification pending | |
| Torch | 059502 |
Hypertherm Torch Assembly 059502
|
Verification pending | |
| Torch | 059503 |
Hypertherm Torch Assembly 059503
|
Verification pending | |
| Torch | 059504 |
Hypertherm Torch Assembly 059504
|
Verification pending | |
| 1 | 228523 |
Hypertherm Torch Body 228523
|
Verification pending | |
| 2 | 075473 |
Hypertherm part 075473
|
Verification pending | |
| 3 | 075503 |
Hypertherm part 075503
|
Verification pending | |
| 4 | 058519 |
Hypertherm O-Ring 058519
|
View on Amazon | |
| 5 | 128639 |
Hypertherm Switch/Sensor 128639
|
Verification pending | |
| 6 | 075571 |
Hypertherm Switch/Sensor 075571
|
Verification pending | |
| 7 | 228522 |
Hypertherm Kit 228522
|
Verification pending | |
| 8 | 128643 |
Hypertherm Kit 128643
|
Verification pending | |
| 9 | 075004 |
Hypertherm part 075004
|
Verification pending | |
| Torch | 128645 |
Hypertherm Torch Assembly 128645
|
Verification pending | |
| 10 | 128710 |
Hypertherm Mounting Sleeve 128710
|
Verification pending | |
| 11 | 228222 |
Hypertherm Torch Lead 228222
|
Verification pending | |
| 12 | 228223 |
Hypertherm Torch Lead 228223
|
Verification pending | |
| 13 | 228224 |
Hypertherm Torch Lead 228224
|
Verification pending | |
| 14 | 228225 |
Hypertherm Torch Lead 228225
|
Verification pending | |
| 15 | 128772 |
Hypertherm Kit 128772
|
Verification pending |
Source: 2023 Hypertherm Torch and Consumables Catalog for Powermax and MAX Plasma Systems, page 86. Catalog page images are used when a cleaned diagram asset is not already available.
Hypertherm plasma support
T100M-2 Machine Torch consumables from the Hypertherm consumables catalog. Confirm machine, torch style, amperage, and process before ordering.
As an Amazon Associate, I earn from qualifying purchases. Buy buttons only appear where a WSP-approved Amazon registry match exists.
| Item # | Part # | Description | Qty | Buy |
|---|---|---|---|---|
| 40 | 120932 |
Hypertherm part 120932
|
Verification pending | |
| 40 | 220006 |
Hypertherm part 220006
|
Verification pending | |
| 60 | 120925 |
Hypertherm Swirl ring 120925
|
Verification pending | |
| 60 | 120925 |
Hypertherm part 120925
|
Verification pending | |
| 60 | 120926 |
Hypertherm Electrode 120926
|
Verification pending | |
| 60 | 120926 |
Hypertherm part 120926
|
Verification pending | |
| 60 | 120928 |
Hypertherm Retaining cap 120928
|
Verification pending | |
| 60 | 120928 |
Hypertherm part 120928
|
Verification pending | |
| 60 | 120929 |
Hypertherm Shield/deflector 120929
|
Verification pending | |
| 60 | 120930 |
Hypertherm part 120930
|
Verification pending | |
| 60 | 120931 |
Hypertherm Nozzle 120931
|
Verification pending | |
| 60 | 120931 |
Hypertherm part 120931
|
Verification pending | |
| 60 | 220007 |
Hypertherm part 220007
|
Verification pending | |
| 80 | 120927 |
Hypertherm part 120927
|
Verification pending | |
| 80 | 120980 |
Hypertherm part 120980
|
Verification pending | |
120979 |
Hypertherm Shield/Deflector 120979
|
Verification pending | ||
220011 |
Hypertherm Nozzle 220011
|
View on Amazon | ||
220011 |
Hypertherm part 220011
|
View on Amazon | ||
220037 |
Hypertherm Electrode 220037
|
Verification pending | ||
220037 |
Hypertherm part 220037
|
Verification pending | ||
220047 |
Hypertherm part 220047
|
Verification pending | ||
220048 |
Hypertherm Retaining cap 220048
|
Verification pending | ||
220048 |
Hypertherm part 220048
|
Verification pending | ||
220051 |
Hypertherm Swirl ring 220051
|
Verification pending | ||
220051 |
Hypertherm part 220051
|
Verification pending | ||
220061 |
Hypertherm part 220061
|
Verification pending | ||
220064 |
Hypertherm part 220064
|
Verification pending | ||
220065 |
Hypertherm Shield/deflector 220065
|
Verification pending | ||
220206 |
Hypertherm part 220206
|
Verification pending |
Source: 2023 Hypertherm Torch and Consumables Catalog for Powermax and MAX Plasma Systems, page 82. Catalog page images are used when a cleaned diagram asset is not already available.
